Four Ball Friction Tester Machine Digital Readout Meter 10000N

Name: Four Ball Friction Tester Machine Digital Readout Meter 10000N
Brand: Lonroy
Price: 1 USD

Brand Name : Lonroy

Model Number : LR-MRS

Certification : ISO ASTM CE

Place of Origin : China

MOQ : 1

Price : Negotaible

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 200

Delivery Time : 5-8 work days

Packaging Details : Wooden package

Temperature control accuracy : ±3℃

Speed control accuracy : ±2r/min

Oil consumption for one test : 10ml

Nominal diameter of the special standard steel ball : φ12.7

Contact Now

Digital Display Lever Type Four-ball Friction Tester Digital Readout Meter

Product Introduction

The LR-MRS Lever Four-ball Friction Testing Machine is a cost-effective laboratory evaluation equipment developed by our company to meet the needs of lubricant research and production users. This testing machine adopts the sliding friction mode and, under extremely high point contact pressure conditions, evaluates the bearing capacity of lubricants, including the maximum no-stall load PB, the sintered load PD, and the comprehensive wear value ZMZ, etc. three indicators.

Product Parameter

Test force
Maximum test force	10000N
Less than 4% of the maximum test force, indication error	±5N
More than 4% of the maximum test force, relative indication error	±1％
Test force loading method	Manual loading of weights
Friction force
Maximum friction force	300N
The relative indication error of the friction force should not be greater than	±3%
Automatic stop due to excessive friction at high load
Test machine heating system
Working temperature range of the heater	indoor temperature~250℃
Temperature control accuracy	±3℃
Spindle speed
Spindle speed range	5~2000r/min (Stepless adjustable)
Speed control accuracy	±2r/min
Oil consumption for one test	10ml
Nominal diameter of the special standard steel ball	φ12.7
Spindle motor power of the testing machine	1.5kW
Spindle control of the testing machine
Time control	Automatic stop when the set time is exceeded
Friction force control	Automatic stop when the set friction force is exceeded
Display and control range of the testing machine's time	1s～9999min
Dimensions of the testing machine (length × width × height)	1300×490×1220(mm)
Main accessories: Surface scratch measurement physical microscope
Magnification of the measuring microscope	25× 100×
Measurement range of surface scratches	0～10mm
Accuracy of the measurement range of surface scratches	0.01mm
